Busbar System Type 630A 3 Phase Disconnect Fuses Switch DNH1-630/31G

Mode:

DNH1-630/31G

Voltage:

380VAC

Rated Current:

160A or other(250A, 400A, 630A, 800A)

Raw Material:

Copper contacts, DMC base, PC cover

Certificate:

TUV, CB, CE RoHS

Installation type:

Fixed type and busbar type

Optional:

With fuse link, micro switch, fuse monitor

Email:

[email protected]

Suitable fuse：

4A,6A,10A,16A,20A,25A,32A,40A,50A,63A,160A(NH00) ,

Keywords:

630 amp disconnect switch, 630A 3 Phase Fused Disconnect Switch, fuser switch, ac fuse switch， Disconnect Fuses

Certification Download PDF Contact Us

Description

Product parameters:630A 3 Phase Disconnect Fuses Switch

Selection Help.

Structure description	Match fuse size	Mounting method	Product model	Item No.
Top connection to the system	3	Busbar type	DNH1-400/31G	DN31331
Connection top with 1NO+1NC auxiliary contactor	3	Busbar type	DNH1-400/31G	DN31341
Connection top with 2 (1NO+1NC auxiliary contactor)	3	Busbar type	DNH1-400/31G	DN31351
Connection bottom	3	Busbar type	DNH1-400/31G	DN31161
Connection bottom with 1NO+1NC auxiliary contactor	3	Busbar type	DNH1-400/31G	DN31171
Connection bottom with 2 (1NO+1NC auxiliary contactor)	3	Busbar type	DNH1-400/31G	DN31181

Parameter Description

With fuse	Rated voltage	Ue	V	AC380	AC660
	Rated current	Ie	A	160	100
	Conventional thermal current	Ith	A	160	100
	Rated short-time withstand current		kA	100	50
	Rated insulation voltage	Ui	V	800
	Rated impulse withstand voltage	Uimp	kV	8
	Utilization category			AC-23B
				AC-22B
				AC-21B
				AC-20B
	Electric endurance times		Times	200

Read GRL 3 Phase Fused Disconnect Switch 630A/30G

3 Phase Fused Disconnect Switch is Divided into fixed installation and busbar installation Disconnect Fuses

Newly developed with electronic functions. At the same time, there are two types of wiring methods, one can be connected by traditional bolts, and the other can be connected by clips.

Fuse switches are manufactured according to international standards such as IEC 60947-3 and DN60269-2.

Fuse switches are manufactured according to international standards such as IEC 60947-3.
