GRL NF1451-P fuse link 2A gG 1140V Cylindrical Cap Fuse-Link with Striker Pin

NF1451-P Fuse Link Overview

NF1451-P cylindrical cap fuse links are suitable for AC systems with a rated voltage of 1140V and rated currents from 2A to 10A, used for overload and short-circuit protection in low-voltage switchgear assemblies.

The product performance meets GB/T 13539.2 / IEC 60269-2.

NF1451-P Fuse Link Technical Parameters

NF1451-P Fuse Link Key Features

• Integrated Striker Pin: Pop-up mechanical pin triggers optional microswitches for remote signaling and alarm automation.
• Standard 14 X 51 mm Fit: Fully compatible with standard 14 X 51 mm modular fuseholders and disconnectors.
• High Breaking Capacity: Premium ceramic body and quartz sand filling ensure high interrupting performance under severe fault conditions.
